Champion 800-RD Features
bullet

3 Possible Machine Settings: Standard Random, Memory Random and Uniform

bullet

Specially suited if your mix of cartons includes tall tippy sizes

bullet

Unique tilt bed ensures top and bottom drives engage the carton at the same time

bullet

Large capacity with no speed penalty over other brands

bullet

Two- 502 Easy Load 2" Tape Heads (Top & Bottom Seal)

bullet

Pop Out and Interchangeable Tape Heads

bullet

Adjustable Legs from 26.75"-36.75" with Casters (Custom Lengths Available)

Tech

Minimum Carton Capacity Maximum Carton Capacity

Maximum Carton Capacity

4.75"L x 5.5"W x 4.75"H

~ L x 20"W x 20"H

(Custom carton sizes available) (Custom carton sizes available

 Required  Service

Belt Speed

120 V, 60hz, 10amp; 85PSIG @ 4CFM

77 Feet per minute
Machine Footprint  Machine Shipping Weight
46"L x 36.5"W x 61.5"H

(Length does not include optional tables)

  525 lbs. (on a pallet)

 IF your application falls outside the parameters you see here please feel free to call or use our simple survey form to get a quote on a modified version of this machine



  Download a .PDF (Acrobat) file of our print brochure. Acrobat reader will be required to view and print this file
