Provides the best solution for tall tippy cartons |
|
Two- 502 Easy Load 2" Tape Heads (Top & Bottom Seal) |
|
Pop Out and Interchangeable Tape Heads |
|
Top Tape Head Can Be Repositioned For Off Centre Seal |
|
Adjustable Legs from 22"-32" with Casters (Custom Lengths Available) |
|
Top Squeezers Properly Mate Top flaps Before Taping |
|
Infeed Table (16" in Length) |
|
Exit Table (16" in Length)
|
|
Minimum Carton Capacity Maximum Carton Capacity |
Maximum Carton Capacity |
|
4.75"L x 4"W x 5.5"H ~ L x 20"W x 20"H |
~ L x 20"W x 20"H (Custom carton sizes available) |
|
Electricity Required |
Belt Speed |
|
120 V, 60hz, 10amp |
77 Feet per minute |
| Machine Footprint | Machine Shipping Weight |
| 64.5"L x
29.75"W x 57.25"H
(Length includes tables) |
385 lbs. (on a pallet) |
IF your application falls outside the parameters you see here please feel free to call or use our simple survey form to get a quote on a modified version of this machine
